Double Layer Pneumatic Air Hose Anti Spark PU Tube Pneumatic Air Tubing

Pneumatic Hose PU PE Air Tube Hose 4 6 8 10 12 14 PE 4*2.5

Short Description:

Pneumatic PU hose

*Made of new imported polyester TPU raw materials, the pipe wall is smooth and uniform, the size is stable, and the working life is long.

*Good resilience, small bending radius, easy to install and cut. Wear resistance, excellent mechanical properties.

*The transparent tube has high transparency, and the medium state is clearly visible.

*The color tube adopts imported weather resistant color master batch, which is bright and will not fade for a long time.

*The working pressure at normal temperature (23C) is 1.0MPa, and the bursting pressure is 3.5MPa. The temperature range for normal use is – 20 ° C~+80 ° C, and the recommended temperature for long-term use is – 10C~+60 ° C.

*Conventional hardness: 95A, 98A, customized hardness: 70A~62D.

*Service medium: air, non corrosive compressed gas and lubricating oil.

EmailContact
  • Details
  • Free Sample
  • Warranty policy

PU double-layer flame retardant tube
PU flame retardant tube, PU ventilation tube, PU double-layer flame retardant tube
--Application field
Applicable to the general working pressure of liquid transportation in the fields of industry, agriculture, food, medicine, civil engineering, fishery, aquaculture, garden irrigation, etc. Such as: pneumatic tube, hydraulic tube, garden water pipe, oil pipeline, water pipeline, oil exploration pipe, sandblasting tube, peristaltic pump hose, industrial robot, pneumatic tools, assembly plant air pressure tools, pressure conveying pipeline.
◆ Water and other fluids.
◆ Can be used as a vacuum straw.
◆ Protective jacket for metal and electronic products
◆ Decorations (such as handles, etc.)
--Product characteristics
Characteristics: The hose produced by TPU material has the properties of tensile resistance, strong tension, high tear strength, wear resistance, bending resistance, penetration resistance, low temperature resistance, hydrolysis resistance, etc., and has good resilience and long service life. This product does not contain plasticizer, is non-toxic and odorless, and is a high-performance environmentally friendly hose. It is the best alternative to PVC and rubber hoses. Type: polyester TPU hose, polyether TPU hose, polycaprolactone TPU hose, low-cost TPU hose Conveying media: chemical liquids, abrasives, food and beverages, oil, water, gas Applicable temperature: -35℃—90℃ Hardness range: 70A—98A
*Excellent softness, small bending radius; good shock resistance; light weight; wide working temperature and working pressure range.
*Excellent chemical properties, minimal pressure loss; constant hardness, long service life.
*Non-toxic, odorless.
*Customizable colors on demand, easy to identify pipelines.
*Comply with ROHS environmental protection requirements.
